Deploying a Node.js application using Docker, Kubernetes, and AWS is a multi-step process that requires building the Docker image, configuring Kubernetes for deployment, and setting up AWS services. Below is an process and commands involved

I'll walk through the steps of deploying a simple Node.js application using Docker, Kubernetes, and AWS.

Image description

Step 1: Set Up Node.js Application
First, create a simple Node.js application. For this example, we'll use a basic Express server.

Create a server.js file:

// server.js
const express = require('express');
const app = express();
const port = 3000;

app.get('/', (req, res) => {
  res.send('First Service from Node.js!');
});

app.listen(port, () => {
  console.log(`Server is running on port ${port}`);
});

Step 2: Dockerize the Node.js Application
Create a Dockerfile:

The Dockerfile defines the environment to run your application.

# Step 1: Use the official Node.js image
FROM node:14

# Step 2: Set the working directory inside the container
WORKDIR /usr/src/app

# Step 3: Copy the application code into the container
COPY . .

# Step 4: Install dependencies
RUN npm install

# Step 5: Expose the application port
EXPOSE 3000

# Step 6: Run the application
CMD ["npm", "start"]

Build the Docker image using below command:

docker build -t node-docker-app .

docker run -p 3000:3000 node-docker-app

Now we can check
our application should now be accessible at http://localhost:3000.

Step 3: Push Docker Image to AWS ECR (Elastic Container Registry)
First, create a repository in ECR on AWS Console:

Go to the ECR section of AWS.

Create a new repository, e.g., node-docker-app.

Then, authenticate Docker with AWS ECR:

aws ecr get-login-password --region us-west-2 | docker login --username AWS --password-stdin .dkr.ecr.us-west-2.amazonaws.com

Reference Link: link:https://docs.aws.amazon.com/AmazonECR/latest/userguide/docker-push-ecr-image.html

Tag the Docker image:
docker tag node-docker-app:latest .dkr.ecr.us-west-2.amazonaws.com/node-docker-app:latest

Push the Docker image to ECR:

docker push .dkr.ecr.us-west-2.amazonaws.com/node-docker-app:latest

Step 4: Create Kubernetes Deployment Configuration
Create a Kubernetes deployment YAML file to manage your Dockerized app.

Create a deployment.yaml file:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: node-docker-app-deployment
spec:
  replicas: 2
  selector:
    matchLabels:
      app: node-docker-app
  template:
    metadata:
      labels:
        app: node-docker-app
    spec:
      containers:
      - name: node-docker-app
        image: .dkr.ecr.us-west-2.amazonaws.com/node-docker-app:latest
        ports:
        - containerPort: 3000

Create a Kubernetes service YAML file:

This exposes your application to the outside world.

Create a service.yaml file:

apiVersion: v1
kind: Service
metadata:
  name: node-docker-app-service
spec:
  selector:
    app: node-docker-app
  ports:
    - protocol: TCP
      port: 80
      targetPort: 3000
  type: LoadBalancer

Step 5: Set Up Kubernetes on AWS (EKS)
Install kubectl and Install eksctl (for creating an EKS cluster)

brew install kubectl

brew install eksctl

Create an EKS cluster:

eksctl create cluster --name nodejs-cluster --region us-west-2 --nodegroup-name nodegroup --node-type t2.micro --nodes 2

Configure kubectl to use your EKS cluster:

aws eks --region us-west-2 update-kubeconfig --name nodejs-cluster

Step 6: Deploy the Application to Kubernetes
Apply the deployment and service files:

kubectl apply -f deployment.yaml
kubectl apply -f service.yaml

Check the status of the deployment:

kubectl get deployments
kubectl get pods

Get the LoadBalancer IP:

kubectl get svc node-docker-app-service

The external IP address will be listed under the EXTERNAL-IP column. You can now access the application via the LoadBalancer's IP.

Step 7: Clean Up
When you're done, you can delete the Kubernetes cluster on AWS to avoid any ongoing charges:

`eksctl delete cluster --name nodejs-cluster --region us-west-2
