Source Code Analysis of DolphinScheduler Master Module

public void notify(Map<String, MasterHeartBeat> masterNodeInfo) {
    List<Server> serverList = masterNodeInfo.values().stream()
            // TODO This filters out busy master nodes.
            .filter(heartBeat -> !heartBeat.getServerStatus().equals(ServerStatus.BUSY))
            .map(this::convertHeartBeatToServer).collect(Collectors.toList());
    // TODO Synchronize master nodes.
    syncMasterNodes(serverList);
}

private void syncMasterNodes(List<Server> masterNodes) {
    slotLock.lock();
    try {
        this.masterPriorityQueue.clear();
        // TODO All master nodes are added to masterPriorityQueue, for example, [192.168.220.1:12345,192.168.220.2:12345].
        this.masterPriorityQueue.putAll(masterNodes);
        // TODO Get the position of the local IP in the queue.
        int tempCurrentSlot = masterPriorityQueue.getIndex(masterConfig.getMasterAddress());
        // TODO Total number of nodes.
        int tempTotalSlot = masterNodes.size();
        // TODO Normally, this should not be less than 0.
        if (tempCurrentSlot < 0) {
            totalSlot = 0;
            currentSlot = 0;
            log.warn("Current master is not in active master list");
        } else if (tempCurrentSlot != currentSlot || tempTotalSlot != totalSlot) {
            // TODO This essentially records the slot index, e.g., with two slots, the index would be 0 or 1.
            totalSlot = tempTotalSlot;
            currentSlot = tempCurrentSlot;
            log.info("Update master nodes, total master size: {}, current slot: {}", totalSlot, currentSlot);
        }
    } finally {
        slotLock.unlock();
    }
}

public void putAll(Collection<Server> serverList) {
    for (Server server : serverList) {
        this.queue.put(server);
    }
    // TODO Updates `hostIndexMap`, storing  -> index mappings.
    refreshMasterList();
}

private void refreshMasterList() {
    hostIndexMap.clear();
    Iterator<Server> iterator = queue.iterator();
    int index = 0;
    while (iterator.hasNext()) {
        Server server = iterator.next();
        String addr = NetUtils.getAddr(server.getHost(), server.getPort());
        hostIndexMap.put(addr, index);
        index += 1;
    }
}

For example, with two Master nodes:
masterCount=2 thisMasterSlot=0  master1
masterCount=2 thisMasterSlot=1  master2

Data in the command table:
1 master2
2 master1
3 master2
4 master1

SELECT *
FROM t_ds_command
WHERE id % #{masterCount} = #{thisMasterSlot}
ORDER BY process_instance_priority, id ASC
LIMIT #{limit};

For example, in `master1`, the table looks like this:
1  master2
2  master1
3  master2
4  master1

However, in `master2`, all commands seem to belong to it, leading to potential duplicate consumption:
1 master1
2 master1
3 master1
4 master1

@Transactional
public @Nullable ProcessInstance handleCommand(String host,
                                               Command command) throws CronParseException, CodeGenerateException {
    // TODO Create process instance
    ProcessInstance processInstance = constructProcessInstance(command, host);
    // Cannot construct process instance, return null
    if (processInstance == null) {
        log.error("Scan command, command parameter is incorrect: {}", command);
        commandService.moveToErrorCommand(command, "Process instance is null");
        return null;
    }
    processInstance.setCommandType(command.getCommandType());
    processInstance.addHistoryCmd(command.getCommandType());
    processInstance.setTestFlag(command.getTestFlag());
    // If the processDefinition is serial
    ProcessDefinition processDefinition = this.findProcessDefinition(processInstance.getProcessDefinitionCode(),
            processInstance.getProcessDefinitionVersion());
    // TODO Check if execution is serial
    if (processDefinition.getExecutionType().typeIsSerial()) {
        saveSerialProcess(processInstance, processDefinition);
        if (processInstance.getState() != WorkflowExecutionStatus.RUNNING_EXECUTION) {
            setSubProcessParam(processInstance);
            triggerRelationService.saveProcessInstanceTrigger(command.getId(), processInstance.getId());
            deleteCommandWithCheck(command.getId());
            // TODO This is a poor design, returning null here affects task triggering
            return null;
        }
    } else {
        // TODO Execute in parallel
        processInstanceDao.upsertProcessInstance(processInstance);
    }

    // TODO Insert a record into `triggerRelation` table linking process instance and triggerCode
    triggerRelationService.saveProcessInstanceTrigger(command.getId(), processInstance.getId());
    // TODO Set parameters for subprocesses
    setSubProcessParam(processInstance);
    // TODO Delete the command
    deleteCommandWithCheck(command.getId());
    return processInstance;
}
