Kubernetes Agent Blind to New Mounts? Demystifying Mount Propagation

How mountPropagation: HostToContainer leverages Linux namespaces to solve a common agent problem

Ever run into this frustrating scenario? You deploy a Kubernetes agent (like an I/O limiter, monitoring tool, or operator) that needs to interact with PersistentVolumes mounted by Kubelet for other pods. It works fine initially, seeing all existing mounts. But then, a new pod gets scheduled, its PV gets mounted by Kubelet... and your agent is completely blind to it! 😠 Restarting the agent fixes it, but that's just a workaround, not a solution.

I recently wrestled with this exact issue while building an I/O limiter that needed device MAJOR:MINOR numbers from pod mounts. Let's dive into why this happens and how to fix it properly using Kubernetes mountPropagation.

The Root Cause: Linux Mount Namespaces

The core of the issue lies in Linux mount namespaces. By default, each container in Kubernetes gets its own isolated mount namespace. Think of it as a private view of the system's mount points. When a container starts, it gets a copy of the host's mount table at that moment.

Crucially, subsequent mount events happening on the host (like Kubelet mounting a new PV under /var/lib/kubelet/pods/) are not automatically reflected inside the container's isolated namespace. This default behavior corresponds to private propagation in Linux terminology.

In Kubernetes, this default isolation is represented by:

mountPropagation: None # (Default if not specified)

This isolation is great for security and preventing containers from interfering with each other or the host, but it causes the "blind agent" problem.

The Solution: Kubernetes mountPropagation

Kubernetes provides the mountPropagation field within a volumeMount definition to control how mount events are shared between the host and the container's namespace. It bridges the isolation gap when needed. There are three modes:

1. None (Default): Complete isolation. No mount events propagate in either direction. (Linux: private)
2. HostToContainer: One-way street! Mount events from the host propagate into the container. Mounts created inside the container do not propagate back to the host. (Linux: rslave - recursive slave). This is exactly what we need for our agent! 👍
3. Bidirectional: Two-way street. Mounts propagate from host to container AND from container back to the host (and other containers in the pod using Bidirectional). (Linux: rshared - recursive shared). Use with extreme caution! This can affect the host system and requires the container to be privileged or have CAP_SYS_ADMIN.

The Recipe: Fixing the Blind Agent

To allow our agent container to see new PVs mounted by Kubelet under /var/lib/kubelet/pods after the agent has started, we need to mount that host directory into the agent and set mountPropagation: HostToContainer:

# Example Pod spec for the agent
spec:
  containers:
  - name: my-observing-agent
    image: my-agent-image:latest
    # Optional: If your agent needs to *do* something with mounts,
    # it might need privileges beyond just seeing them.
    # Bidirectional *requires* privileged or CAP_SYS_ADMIN.
    # HostToContainer itself doesn't require extra privileges just to see mounts.
    # securityContext:
    #   privileged: false
    #   capabilities:
    #     add: ["SYS_ADMIN"] # Example if needed for other operations
    volumeMounts:
    - name: kubelet-pods-dir
      # The path inside the container where the host dir will be mounted
      mountPath: /mnt/kubelet-pods
      # The magic setting!
      mountPropagation: HostToContainer
  volumes:
  - name: kubelet-pods-dir
    hostPath:
      # The directory on the host we want to observe
      path: /var/lib/kubelet/pods
      # Ensures the path exists on the host
      type: DirectoryOrCreate

With this configuration, any new directory or mount point created by Kubelet under /var/lib/kubelet/pods on the host will automatically appear under /mnt/kubelet-pods inside the my-observing-agent container, without requiring a restart. Problem solved! ✅

Under the Hood: How It Works

What happens when you set HostToContainer?

1. Kubelet: Sees mountPropagation: HostToContainer in the Pod spec.
2. CRI Request: Kubelet translates this to the corresponding enum (PROPAGATION_HOST_TO_CONTAINER) in its request to the Container Runtime Interface (CRI).
3. Container Runtime (containerd, CRI-O): Receives the request and uses Linux system calls (specifically the mount syscall with flags like MS_SLAVE | MS_REC) to configure the container's mount point (/mnt/kubelet-pods in our example) as a recursive slave (rslave) of the corresponding host mount point (/var/lib/kubelet/pods).
4. Propagation: Because the container's mount is now a slave of the host's mount, any mount events occurring under the host path are automatically propagated by the Linux kernel into the container's mount namespace at the slave mount point.

Important Considerations

• Security (Bidirectional): Seriously, be careful with Bidirectional. A container mount propagating back to the host can have significant security implications, especially in multi-tenant clusters. It generally requires the container to run as privileged or have CAP_SYS_ADMIN.
• Privileges (HostToContainer): Simply observing mounts with HostToContainer doesn't inherently require extra privileges. However, if your agent needs to perform actions within those propagated mounts (like modifying files owned by root, mounting things itself), it might need appropriate capabilities (CAP_SYS_ADMIN) or run as privileged, independent of the mountPropagation setting itself.
• Debugging: If things aren't working, check the mount table inside the container (findmnt or cat /proc/self/mountinfo) and compare it to the host's. Look for the master: entries or propagation flags (shared, slave) associated with your mount point.
• Historical Note: For a brief period around Kubernetes 1.10, the default was accidentally changed to HostToContainer before being reverted. If you're managing a very old cluster, be aware of this possibility (#62462).

Conclusion

Kubernetes mountPropagation is a powerful mechanism rooted in Linux mount namespaces that allows you to selectively break container isolation for specific use cases. Understanding the HostToContainer mode (rslave) is key to solving the common problem of agents needing visibility into dynamically created host mounts, like those managed by Kubelet. By applying it correctly, you can build more robust and reliable agents and operators without resorting to restarting them.
